The highest-performing geogrid combining coextrusion, advanced material science, and optimized geometry
Tensar InterAx® Geogrids represent the cutting edge in geosynthetic technology for ground stabilization. This next-generation product is engineered specifically for trafficked surfaces and foundations, offering a unique combination of coextrusion, advanced material science, and optimized geometry.

InterAx® Geogrids stand out for their exceptional durability and resistance to environmental factors. They are 100% UV resistant and do not rust, leach, or degrade when exposed to direct sunlight, ensuring long-lasting performance in various conditions.

The hallmark of InterAx® Geogrids is their innovative geometry. This unique design allows for maximum confinement of aggregate, which translates to significant benefits in construction efficiency and material usage. By enabling better stabilization with less material, InterAx® Geogrids offer both economic and environmental advantages in infrastructure projects.

As a versatile solution, these geogrids have proven their effectiveness across a wide range of applications, from subgrade stabilization and pavement reinforcement to the creation of robust work platforms. Their ability to enhance soil stability while reducing the need for traditional materials makes InterAx® Geogrids a game-changing technology in modern construction and civil engineering practices.

Why Choose?

• Highest-performing geogrid on the market
• Over 11M+ square yards installed since launch
• Potential for up to 70% aggregate reduction
• Can reduce carbon emissions by up to 65%
• Speeds up construction and saves on costs

Core Functions

• Subgrade stabilization
• Pavement reinforcement
• Work platform stabilization
• Aggregate confinement
• Soil reinforcement

Key Benefits

• Reduces aggregate fill requirements
• Potential elimination of undercut
• Improves compaction
• Restricts movement over time
• Enhances long-term performance
• Withstands severe weather events and climate change impacts

Capabilities

• Works with a broad range of aggregates and granular materials
• Effective in pH and chemically aggressive conditions
• Compatible with Tensar+ design software
• Can be excavated through for utilities and other installations

Technical Advantages

• 40% higher aspect ratio on all ribs compared to conventional grids
• “Crush-fit” outer layers for better aggregate hold
• Repeating, open hexagonal element for improved compaction
• Greater range and distribution of aperture shapes and sizes

Applications

• Public roads
• Commercial and industrial sites
• Residential developments
• Airports
• Railways
• Crane pads
• Parking lots
• Haul and access roads

Product Range

• NXL series
• NX850
• NX750
• NX650

Additional Features:

• • Fully compatible with Tensar+ design software
  • Proven success in numerous projects worldwide
  • Tested at the US Army Corps of Engineers’ Research Center
  • Contributes to more resilient and sustainable infrastructure

<

Get the benefit of optimized geometry at a more economical cost
Tensar H-Series Geogrids represent an economical yet high-performing solution for ground stabilization in various construction applications. These geogrids are the result of extensive research and development, combining over 10,000 hours of R&D efforts from 12 product teams. Engineered to provide optimal performance at a more cost-effective price point than the advanced InterAx® geogrid, H-Series Geogrids offer an ideal balance of efficiency and economy.

The H-Series stands out for its optimized geometry, which enhances the interlock of fill materials to create a highly efficient stabilized layer. This innovative design makes these geogrids particularly effective for stabilizing soft subgrades, constructing access roads, and improving pavement performance. Furthermore, H-Series Geogrids provide a resilient solution for building trafficked surfaces capable of withstanding severe weather and challenging environmental conditions, ensuring long-term durability and performance.

Why Choose?

• More economical than advanced InterAx® geogrid
• Higher performance than TriAx® geogrid
• Proven to reduce initial and lifecycle costs
• Decreases construction time
• Offers sustainability benefits on projects
• Compatible with Tensar+ design software

Core Functions

• Subgrade stabilization
• Access road construction
• Pavement performance improvement
• Soil reinforcement
• Aggregate interlock enhancement

Key Benefits

• Cost-effective solution without sacrificing performance
• Works well with a broad range of aggregates and granular materials
• Reduces need for expensive fill materials
• Enhances project sustainability
• Improves overall construction efficiency

Capabilities

• Withstands severe weather and challenging environmental conditions
• Creates an efficient stabilized layer through optimized geometry
• Allows for use of lower-cost aggregate options
• Supports sustainable product specifications

Technical Advantages

• Optimized geometry for enhanced fill material interlock
• Greater range and distribution of aperture shapes and sizes
• 100% UV resistant
• Does not rust, leach, or degrade in direct sunlight

Applications

• Road construction
• Parking lots
• Industrial platforms
• Residential developments
• Temporary access roads
• Railway construction
• Airport runways and taxiways

Product Range

• HX5.5
• HX145
• HX165

Additional Features:

• Supported by its own Environmental Product Declaration (EPD)
• First post-industrial product offering from Tensar
• Can be excavated through for utility installations
• Provides a more resilient infrastructure solution

Multi-axial geogrid leveraging triangular geometry to achieve higher performance
Tensar TriAx® Geogrid represents a significant advancement in geosynthetic technology, specifically engineered for trafficked surfaces. This innovative product harnesses the power of triangular geometry – one of the most stable and widely used shapes in construction – to deliver enhanced in-plane stiffness and superior performance. The TriAx® Geogrid’s unique design features a multi-directional structure with improved rib and junction geometry, offering the construction industry a more effective alternative to conventional materials and practices.

Manufactured from a punched polypropylene sheet, TriAx® Geogrid is oriented in multiple, equilateral directions to form its distinctive triangular apertures. This results in high radial stiffness throughout a full 360 degrees, creating a more efficient product that optimizes in-service stress transfer from aggregate to the stabilizing geogrid. With over 500 million square meters installed globally and performance validation testing equivalent to 2 million ESALs (Equivalent Single Axle Loads), TriAx® Geogrid has proven its effectiveness and durability in various applications.

Why Choose?

• Leverages stable triangular geometry for enhanced performance
• Provides superior 360° stiffness
• Offers up to 50% savings in aggregate thickness
• Extensively tested and validated in real-world applications
• Improves pavement life and reduces maintenance needs
• Environmentally friendly solution reducing excavation and material usage

Core Functions

• Soil and aggregate stabilization
• Pavement reinforcement
• Subgrade improvement
• Load distribution
• Rutting reduction

Key Benefits

• Enhanced in-plane stiffness
• Improved stress distribution
• Reduced permanent deformation
• Increased bearing capacity
• Potential for thinner pavement structures
• Faster construction times

Capabilities

• Efficient confinement of aggregate particles
• High junction strength and stiffness
• Mitigation of radial stress from trafficked surfaces
• Reduction of subgrade stress
• Improvement of internal drainage characteristics

Technical Advantages

• Unique hexagonal junction shape
• Rigid triangular aperture geometry
• High rib profile for optimal aggregate interlock
• Multi-directional load absorption and distribution
• Manufactured from durable polypropylene material

Applications

• Paved and unpaved roads
• Railway construction
• Parking lots and industrial yards
• Airport runways and taxiways
• Temporary access roads and working platforms
• Full-depth pavement designs

Product Range

• TX150
• TX160
• TX170
• TX190L
• TX5 (for full-depth pavement designs)
• TX7 (for full-depth pavement designs)

Additional Features:

• Compatible with Tensar design software for optimized solutions
• Supported by extensive research and full-scale testing
• Can be used in mechanically stabilized layers for increased pavement life
• Allows for possible reduction in pavement thickness for a given design life
• Enhances the effective strength of pavement structures

Composite product family combining confinement properties of geogrid with added assurance of a nonwoven geotextile
Tensar FilterGrid™ represents an innovative marriage of geosynthetic materials, combining the superior stabilization properties of Tensar’s TriAx® geogrid with the separation and filtration benefits of a nonwoven geotextile. This composite product addresses the dual needs often encountered in challenging soil conditions: the stabilization of aggregate layers and the separation of fine-grained subgrade soils from granular materials.

Developed in response to situations where both geogrid and geotextile are required, FilterGrid™ allows for a single-step installation process, saving time and labor on construction sites. The product maintains the full interlock capability of the TriAx® geogrid with aggregate materials, ensuring that the stabilization function is not compromised. Meanwhile, the attached nonwoven geotextile provides reliable separation and filtration, preventing the migration of fine soil particles while allowing water to pass through.

FilterGrid™ is particularly valuable in scenarios where the gradation of subgrade soils and available granular material doesn’t allow for natural filtration, or when designers lack sufficient subgrade soil data. By combining multiple geosynthetic functions into one product, Tensar FilterGrid™ offers engineers and contractors an efficient, effective tool for building better infrastructure.

Why Choose?

• Combines stabilization, separation, and filtration in one product
• Saves time and labor with single-step installation
• Ensures both aggregate confinement and subgrade separation
• Optimizes structural thickness, reducing material costs
• Backed by Tensar’s expertise in geosynthetic technology

Core Functions

• Aggregate stabilization
• Soil separation
• Filtration
• Load distribution
• Subgrade improvement

Key Benefits

• Improves speed of construction
• Reduces fill requirements
• Enhances performance and durability of structures
• Provides added assurance in challenging soil conditions
• Simplifies material specification and installation

Capabilities

• High in-plane stiffness through lateral restraint
• Effective confinement of aggregate particles
• Prevents migration of fine soil particles
• Allows water passage while maintaining separation
• Maintains modulus of aggregate material over time

Technical Advantages

• Combines TriAx® geogrid technology with nonwoven geotextile
• Optimized for full aggregate interlock
• Provides filtration based on geotextile openings
• Suitable for various fill materials and subgrade conditions
• Engineered for long-term separation performance

Applications

• Paved and unpaved roadways
• Airfields
• Crane pads
• Working platforms
• Railway construction
• Parking lots
• Temporary access roads

Product Range

• FG30
• FG60
• FG7
• FG90

Additional Features:

• Compatible with Tensar design software for optimized solutions
• Supported by Tensar’s technical expertise and customer support
• Can be customized for specific project requirements
• Contributes to more sustainable construction practices
• Offers potential for reduced maintenance over structure lifespan

Degradation-resistant solution carries high tensile loads applied in one direction
Tensar Uniaxial (UX) Geogrids represent a significant advancement in geosynthetic technology, specifically designed for high-strength soil reinforcement applications. These geogrids are manufactured from select grades of high-density polyethylene (HDPE) resins, which are highly oriented to resist elongation (creep) when subjected to heavy loads over extended periods. The unique manufacturing process involves punching and drawing a homogenous polymer sheet, resulting in a uniform and consistent product that doesn’t require additional weaving, coating, or welding to maintain its integrity.

With over 40 years of production history and more than 400 million square feet installed worldwide, Tensar UX Geogrids have proven their effectiveness and durability in various challenging environments. Their open aperture structure allows for superior interlocking with fill materials, providing excellent load transfer from soil to geogrid. This makes them ideal for wall and slope applications, including retaining walls, bridge abutments, and steep reinforced slopes.

Tensar UX Geogrids are characterized by their ability to carry high tensile loads applied in one direction (along the roll length), making them the go-to solution for projects requiring unidirectional reinforcement. Their robust design and superior chemical resistance allow for use in both dry and wet environments, even in soils with pH levels as high as 12, ensuring long-term performance and a design life of up to 120 years.

Why Choose?

• Over 40 years of proven performance in global projects
• Highly resistant to installation damage and long-term degradation
• Can withstand pH levels up to 12 in soil environments
• Design life of 120+ years
• Superior junction strength for high-strength connections
• Compatible with various backfill materials, including on-site soils and recycled concrete

Core Functions

• High-strength soil reinforcement
• Tensile load distribution
• Soil stabilization
• Erosion control
• Long-term structural support

Key Benefits

• Reduces material and construction time by up to 60% compared to traditional reinforced concrete structures
• High resistance to dynamic shock loading and seismic activity
• Allows for the use of native (on-site) soil as backfill
• Withstands differential settlement
• Provides aesthetically appealing structures
• Reduces traffic disruption and lane closure during installation

Capabilities

• Carries high tensile loads in one direction (along roll length)
• Interlocks effectively with fill material
• Resists creep under sustained loads
• Performs in both dry and wet environments
• Maintains strength in chemically aggressive soils

Technical Advantages

• Manufactured through a unique punching and drawing process
• Uniform and consistent product without weaving, coating, or welding
• Superior junction strength
• Highly oriented polymer structure
• Open aperture design for optimal soil interaction

Applications

• Retaining wall systems
• Bridge abutments
• Steep reinforced slopes
• Embankments on soft subgrades
• Landfill liner reinforcement
• Mining applications
• Vegetated retaining walls

Product Range

• UX1100 MSE
• UX1400 MSE
• UX1500 MSE
• UX1600 MSE
• UX1700 MSE
• UX1800 HS

Additional Features:

• Easy to handle and install
• Available in various strengths to suit project requirements
• Integral component of TensarTech Wall Systems
• Extensively tested and certified for long-term performance
• Contributes to sustainable construction practices

Tensar’s original geogrid invention
Tensar Biaxial Geogrids, known as the original geogrid technology developed by Tensar, have been a cornerstone in soil stabilization projects for over three decades. Designed for mechanical ground stabilization, these geogrids have been successfully implemented in more than half a million projects worldwide, including roads, reinforced foundations, and working platforms. The technology behind Tensar Biaxial Geogrids involves precise blends of polypropylene, copolymers, and additives. This combination ensures the geogrids can handle high, short-term dynamic loads or moderate loads over extended periods, making them versatile and reliable. Although newer geogrid technologies, such as Tensar TriAx and InterAx Geogrids, offer enhanced performance and cost-effectiveness, Tensar Biaxial Geogrids remain a foundational choice for many applications due to their proven track record and established performance.

Why Choose?

• Proven Performance: Over 30 years of successful use in more than 500,000 projects globally.
• Cost-Effective: Lower initial cost compared to advanced geogrid technologies.
• Reliable Technology: Time-tested biaxial design for effective soil stabilization.

Core Functions

• Soil Stabilization: Enhances load distribution and minimizes deformation in soil.
• Load Transfer: Efficiently transfers loads across a larger area to improve structural integrity.
• Foundation Reinforcement: Supports the creation of stable foundations for various structures.

Key Benefits

• Durability: Long-lasting performance under high and moderate loads.
• Reduced Aggregate Needs: Effective in reducing the volume of aggregate required.
• Versatility: Suitable for a wide range of applications, including roads and working platforms.
• Economic Efficiency: Lower initial investment while still delivering reliable performance.

Capabilities

• Dynamic Load Resistance: Handles short-term dynamic loads effectively.
• Moderate Load Handling: Performs well under moderate loads over extended periods.
• Versatile Applications: Applicable in roads, foundations, and working platforms.

Technical Advantages

• Innovative Materials: Utilizes advanced polypropylene blends for enhanced strength and durability.
• Proven Design: Based on the original biaxial geogrid technology developed by Tensar.
• Established Performance: Demonstrated success in a wide variety of challenging environments.

Applications

• Road Construction: Stabilizes subgrades and enhances road performance.
• Reinforced Foundations: Provides support for foundations in weak soils.
• Working Platforms: Ensures stability for construction and industrial platforms.

Product Range

• BX1100: General purpose geogrid with standard performance.
• BX1120: Enhanced version for more demanding applications.
• BX1200: High strength for heavier load applications.
• BX1300: Offers increased performance for critical projects.
• BX1500: Superior strength for high-load scenarios.
• BXSQ100: Square mesh geogrid for specialized applications.
• BXSQ1515: Increased mesh size for specific project needs.
• BXSQ2020: Larger mesh for enhanced performance.
• BXSQ2525: High-capacity geogrid for extensive reinforcement.
• BXSQ3030: Maximum mesh size for the most demanding applications.

Tensar Biaxial Geogrids are a testament to the durability and reliability of geosynthetic reinforcement technology. While newer technologies offer advanced performance and cost savings, the original biaxial design continues to serve as a dependable and effective solution for a wide range of stabilization projects.
